Description
Product details
| Gross weight |
4.89 kg |
| Net weight |
4.69 kg |
| Ambient temperature [°C] [Max] |
50 °C |
| Ambient temperature [°C] [Min] |
0 °C |
| Ambient temperature [°F] [Max] |
122 °F |
| Ambient temperature [°F] [Min] |
32 °F |
| ATEX compliance |
Ex II 2G cb T6 / Ex II 3G c T6 |
| Body material |
AISI 304 |
| Country of origin |
Denmark |
| Displacement [cm³/rev] |
6.3 cm3/rev |
| Displacement [in³/rev] |
0.38 in3/rev |
| Drain connection size (metric) |
M6 |
| Drain connection standard |
Metric |
| Drain connection type |
Thread |
| Flow [gpm] [Max] |
4.71 gal/min |
| Flow [gpm] [Min] |
1.43 gal/min |
| Flow [l/min] [Max] |
18.1 L/min |
| Flow [l/min] [Min] |
5.49 L/min |
| Inlet connection size [in] |
1/2 in |
| Inlet connection standard |
BSPP |
| Inlet connection type |
Thread |
| Inlet pressure [barg] [Max] |
4 barg |
| Inlet pressure [barg] [Min] |
0 barg |
| Inlet pressure [psig] [Max] |
58 psig |
| Inlet pressure [psig] [Min] |
0 psig |
| Inlet pressure peak [barg] [Max] |
4 barg |
| Inlet pressure peak [psig] [Max] |
58 psig |
| Media temperature [°C] [Max] |
50 °C |
| Media temperature [°C] [Min] |
2 °C |
| Media temperature [°F] [Max] |
122 °F |
| Media temperature [°F] [Min] |
36 °F |
| Outlet connection size [in] |
1/4 in |
| Outlet connection standard |
BSPP |
| Outlet connection type |
Thread |
| Outlet pressure [barg] [Max] |
100 barg |
| Outlet pressure [barg] [Min] |
30 barg |
| Outlet pressure [psig] [Max] |
1450 psig |
| Outlet pressure [psig] [Min] |
435 psig |
| Outside dimensions of packaging LxWxH [in] |
10,7×5,9×5,4 |
| Outside dimensions of packaging LxWxH [mm] |
274x151x137 |
| Product group |
Pump |
| Product name |
PAHT G pumps |
| Seal Material |
NBR |
| Serviceable |
Spare parts PAHT G 2/4/6.3 |
| Sound pressure level [dB(A)] |
76 dBA |
| Speed continuous[rpm] [Min] |
1000 rpm |
| Speed [rpm] [Max] |
3000 rpm |
| Speed [rpm] [Min] |
1000 rpm |
| Type |
PAHT G 2-6.3 |
| Type designation |
PAHT G 6.3 Ex |
| Ambient temperature [°C] [Max] |
50 °C |
| Ambient temperature [°C] [Min] |
0 °C |
| Ambient temperature [°F] [Max] |
122 °F |
| Ambient temperature [°F] [Min] |
32 °F |
| ATEX compliance |
Ex II 2G cb T6 / Ex II 3G c T6 |
| Body material |
AISI 304 |
| Country of origin |
Denmark |
| Displacement [cm³/rev] |
6.3 cm3/rev |
| Displacement [in³/rev] |
0.38 in3/rev |
| Drain connection size (metric) |
M6 |
| Drain connection standard |
Metric |
| Drain connection type |
Thread |
| Flow [gpm] [Max] |
4.71 gal/min |
| Flow [gpm] [Min] |
1.43 gal/min |
| Flow [l/min] [Max] |
18.1 L/min |
| Flow [l/min] [Min] |
5.49 L/min |
| Inlet connection size [in] |
1/2 in |
| Inlet connection standard |
BSPP |
| Inlet connection type |
Thread |
| Inlet pressure [barg] [Max] |
4 barg |
| Inlet pressure [barg] [Min] |
0 barg |
| Inlet pressure [psig] [Max] |
58 psig |
| Inlet pressure [psig] [Min] |
0 psig |
| Inlet pressure peak [barg] [Max] |
4 barg |
| Inlet pressure peak [psig] [Max] |
58 psig |
| Media temperature [°C] [Max] |
50 °C |
| Media temperature [°C] [Min] |
2 °C |
| Media temperature [°F] [Max] |
122 °F |
| Media temperature [°F] [Min] |
36 °F |
| Outlet connection size [in] |
1/4 in |
| Outlet connection standard |
BSPP |
| Outlet connection type |
Thread |
| Outlet pressure [barg] [Max] |
100 barg |
| Outlet pressure [barg] [Min] |
30 barg |
| Outlet pressure [psig] [Max] |
1450 psig |
| Outlet pressure [psig] [Min] |
435 psig |
| Outside dimensions of packaging LxWxH [in] |
10,7×5,9×5,4 |
| Outside dimensions of packaging LxWxH [mm] |
274x151x137 |
| Product group |
Pump |
| Product name |
PAHT G pumps |
| Seal Material |
NBR |
| Serviceable |
Spare parts PAHT G 2/4/6.3 |
| Sound pressure level [dB(A)] |
76 dBA |
| Speed continuous[rpm] [Min] |
1000 rpm |
| Speed [rpm] [Max] |
3000 rpm |
| Speed [rpm] [Min] |
1000 rpm |
| Type |
PAHT G 2-6.3 |
| Type designation |
PAHT G 6.3 Ex |
Flow [gpm] [Max]: 4.710, Flow [l/min] [Max]: 18.100, Outlet pressure [barg] [Max]: 100, Speed [rpm] [Max]: 3000, Speed [rpm] [Min]: 1000, ATEX compliance: Ex II 2G cb T6 / Ex II 3G c T6, Body material: AISI 304
