Description
Product details
| Gross weight |
6 kg |
| Net weight |
5.6 kg |
|
VCM 92 Flange to 3 VIC |
| Inlet Connection |
Flange |
| Opening pressure [barg] |
0.1 barg |
| Opening pressure [psig] |
7.2 psig |
| Operating pressure [barg] [Max] |
70 barg |
| Operating pressure [psig] [Max] |
1015 psig |
| Outlet connection |
Victaulic 3 in |
| Pressure loss at max. Flow [barg] |
0.4 barg |
| Pressure loss at max. Flow [psig] |
7.8 psig |
| Product group |
Valve |
| Product name |
Check valves |
| Rated flow [gpm] |
405 gal/min |
| Rated flow [m³/h] |
92 m3/h |
| Type |
VCM |
| Type designation |
VCM 92 Flange to 3 VIC |
|
VCM 92 Flange to 3 VIC |
| Inlet Connection |
Flange |
| Opening pressure [barg] |
0.1 barg |
| Opening pressure [psig] |
7.2 psig |
| Operating pressure [barg] [Max] |
70 barg |
| Operating pressure [psig] [Max] |
1015 psig |
| Outlet connection |
Victaulic 3 in |
| Pressure loss at max. Flow [barg] |
0.4 barg |
| Pressure loss at max. Flow [psig] |
7.8 psig |
| Product group |
Valve |
| Product name |
Check valves |
| Rated flow [gpm] |
405 gal/min |
| Rated flow [m³/h] |
92 m3/h |
| Type |
VCM |
| Type designation |
VCM 92 Flange to 3 VIC |
Inlet Connection: Flange, Opening pressure [barg]: 0.1, 7.2 psig, Outlet connection: Victaulic 3 in, Rated flow [gpm]: 405.0, Rated flow [m³/h]: 92.0
