Description
Product details
| Gross weight |
43 kg |
| Net weight |
27 kg |
| Color |
RED |
|
Housing 40†|
| Drain connection type |
1†Vic. Cut groove |
| Fit to element |
180Z0653 |
| Flow [gpm] [Max] |
264 gal/min |
| Flow [l/min] [Max] |
1000 L/min |
| Flow [m³/h] [Max] |
60 m3/h |
| Housing diameter [in] |
10.62 in |
| Housing diameter [mm] |
270 mm |
| Housing length [in] |
54.48 in |
| Housing length [mm] |
1384 mm |
| Inlet Connection |
3†Vic. Cut groove |
| Materials Caps |
Polypropylene |
| Materials Housing |
GRP Glass reinforced polypropylene |
| Materials Victaulic fittings |
Acetal |
| Operating temperature [°C] [Max] |
60 °C |
| Operating temperature [°F] [Max] |
140 °F |
| Outlet connection |
3†Vic. Cut groove |
| Pressure at 113 °F [psig] [Max] |
232 psig |
| Pressure at 45 °C [barg] [Max] |
16 barg |
| Product group |
Accessory |
| Product name |
Filters |
| Seal Material |
Silicone PTFE |
| Type |
Filter housing |
| Type designation |
Filter housing |
| Vent Connection |
¼†BSP |
| Color |
RED |
|
Housing 40†|
| Drain connection type |
1†Vic. Cut groove |
| Fit to element |
180Z0653 |
| Flow [gpm] [Max] |
264 gal/min |
| Flow [l/min] [Max] |
1000 L/min |
| Flow [m³/h] [Max] |
60 m3/h |
| Housing diameter [in] |
10.62 in |
| Housing diameter [mm] |
270 mm |
| Housing length [in] |
54.48 in |
| Housing length [mm] |
1384 mm |
| Inlet Connection |
3†Vic. Cut groove |
| Materials Caps |
Polypropylene |
| Materials Housing |
GRP Glass reinforced polypropylene |
| Materials Victaulic fittings |
Acetal |
| Operating temperature [°C] [Max] |
60 °C |
| Operating temperature [°F] [Max] |
140 °F |
| Outlet connection |
3†Vic. Cut groove |
| Pressure at 113 °F [psig] [Max] |
232 psig |
| Pressure at 45 °C [barg] [Max] |
16 barg |
| Product group |
Accessory |
| Product name |
Filters |
| Seal Material |
Silicone PTFE |
| Type |
Filter housing |
| Type designation |
Filter housing |
| Vent Connection |
¼†BSP |
Flow [m³/h] [Max]: 60.00, Flow [gpm] [Max]: 264.000, Inlet Connection: 3†Vic. Cut groove, Outlet connection: 3†Vic. Cut groove
