Description
Parts List
| Item | Part No. | Qty. | |
| 4 | 12765A | 5/16″ – 24 x 1.12 Impeller Bolt | 1 |
| 5 | 13778 | O-Ring | 2 |
| 6 | 13777 | Prime/Drain Plug | 2 |
| 7 | V10118 | 5/16″ Lock Washer | 9 |
| 8 | 15772 | 5 Vane Impeller | 1 |
| 9 | 12716 | Pump Slinger | 1 |
| 10 | 12715A | 5/16″ – 24 x 1.75 HHCS | 13 |
| 11 | 12774VA | Impeller Bolt Gasket | 1 |
| 12 | 12719A | Body O-Ring | 1 |
| 13 | 12705 | Check?Valve | 1 |
| 14 | 15702 | Volute | 1 |
| 15 | 15703 | Rear Bracket | 1 |
| 16 | 12902A | 3/16″ sq x 5/8″ Key | 1 |
| 17 | 12901 | 5/16″ Flat Washer | 4 |
| 18 | 12710 | O-Ring | 1 |
| 19 | 12717 | O-Ring | 4 |
| 20 | 12713V | Seal Assembly | 1 |
| 20 | 12713SD | Severe Duty Seal | 1 |
| 21 | 15712 | Body | 1 |
| 22 | 17013 | Flange Gasket | 2 |
| 23 | 17000 | Threaded Flange | 2 |
| 24 | 17019 | 5/16″ – 18 x 0.75 HHCS | 8 |
| 25 | V10118 | 5/16″ Lock Washer | 8 |
