Description
Features:– Operating range of 0.3 to 20 ft/s (0.1 to 6m/s)
– Wide turndown ratio of 66:1
– Open-Collector output
– Highly repeatable output
– Simple, economical design
– Installs into pipe sizes 5″ to 8″
– High resolution and noise immunity
– Test certificate include for -X0 and -X1
– Chemically resistant materials
Applications:
– Pure Water Production
– Filtration Systems
– Chemical Production
– Liquid Delivery Systems
– Pump Protection
– Scrubber/Gas Stacks
– Gravity Feed Lines
– Not Suitable for Gas
– Sodium Hypochlorite transfer/injection/batching (3-2536-U0)
Alternate Part Number: 198 864 514, 198864514Specifications
– Sensor Body: Polypropylene
– Sensor Rotor: Black PVDF
– Pin Material: Titanium
– O-ring: FPM
– Operating Range: 0.3 to 20 ft/s
– Pipe Size: 5″ to 8″
– Max Temperature/Pressure Rating: 180 psi @ 68°F
25 psi @ 185°F
– Operating Temperature: 0-185°F
