Description
Features:– Multiple sensor types supported with one instrument
– Dial type digital bar graph
– Modules are field installable and replaceable anytime
– Optional relay module for addition of two dry contact relays
– Optional H COMM Module for two-way communication
– Optional Batch Module for Batch control
– One 4 to 20 mA output in the base unit. One additional 4 to 20 mA available with optional module
– Rear enclosure kits for panel, wall or pipe mounting
– Warning and Relay LED indicators for “at a glance” visibility
– Customizable features including digital label for custom identification
– Optional PC COMM configuration tool for configuration at a PC
Applications:
– Wastewater Treatment
– Reverse Osmosis
– Deionization
– Ultra Pure Water
– Two Bed System
– Mixed bed System
– Chemical Manufacturing/Addition
– Metal and Plastic Finishing
– Fume Scrubber
– Cooling Towers
– Media Filtration
Replaces Older Obsolete: 3-8850-1
Alternate Part Numbers: 159001695, 159 001 695 Specifications
– Mount Type: Panel
– Number of Inputs: 1
– Output: Up to (2) with 4 to 20 mA output module
– Measurement Type: Flow, pH/ORP, Conductivity/Resistivity, Salinity, Pressure, Temperature, Level, Dissolved Oxygen, Batch or user-defined (via 8058)
– Accuracy: +/- 0.5% of reading
– Power: 10.8 to 35.2 VDC
– Operating Temperature: 14°F to 158°F
– Enclosure: NEMA 4X/IP65
– Shipping Weight: 0.7 lbs
– Standards and Approvals: CE, FCC, UL, CUL
RoHS Compliant, China RoHS
Manufactured Under ISO 9001 for quality and ISO 14001 for Environmental Management and OHSAS 18001 for occupational health and saftey
