Description
Harmsco® Hurricane® Swing Bolt filter housings provide unsurpassed performance. Their unique design separates dense solids prior to cartridge filtration for extended filter life, increased dirt holding capacity and reduced maintenance costs.
Features
– Patented Up-Flow Design
– NSF 61 Listed
– Electro-polished finish – standard
– “Swing Bolt” closure system
– Combination cyclone separator and cartridge filter in single compact design
– Four sizes for greater utility – one, three, five and eight cartridges
– 304 stainless steel housing and internal components – standard
– The industry’s largest selection of cartridge options
– Built to ASME design standards
– Coated option available
– Flow rates up to 1,200 GPM
– Maunfactured in the USA
Applications
– Municipal Drinking Water – Industrial Waste Water Treatment
– Cooling Tower Filtration – Reverse Osmosis Pre-Filtration
– Desalination Pre-Filtration (Coated Option) – Ground Water Remediation
– Surface Water Treatment Rule (SWTR) LT2 – Ground Water Under Direct Influence (GUDI)
Specifications
– Holds (1) 170 series Hurricane Cartridge
| Filter Model | HUR 1x170FL |
| Height | 48″ |
| Width |
15-1/2″ |
| Diameter |
11″ |
| Inlet Height |
23-5/8″ |
| Outlet Height |
9-3/4″ |
| Pipe Size I/O NPS |
2″ Flange |
| Drain Size |
3/4″ |
| Floor Space |
1.8 ft2 |
| Service Height |
77″ |
| Shipping Weight |
150 lbs. |
| Recommended Flow Rate |
Up To 105 GPM |
| Max. Flow Rate |
Up To 150 GPM |
– Electropolished finish
– Built to ASME design standards
– Standpipes – Stainless Steel
– Inlet/Outlet – flanged connections
– O-Ring Hosuing Seal, swing bolt closure
– Pressure – up to 150 psi (10 bar) max
– Temperature – up to 140°F (60° C) with standard cartridges. Up to 200° F (93° C) with HT cartridges, and 250° F (121° C) with HTM high temperature cartridges.
