Description
This instrument is designed to be extremely accurate, fast, and simple to use in diverse water quality applications. Advanced features include the ability to select from 3 different solution types that model the characteristics of the most commonly encountered type of water, proprietary temperature compensation and TDS conversion algorithms; highly stable microprocessor-based circuitry, user-intuitive design; and waterproof housing. A true, one-handed instrument, the PT1 is easy to calibrate and easy to use. To take a measurement, you simply press a button and then dip the pen in the solution. Results are displayed in seconds.
Features
– Accuracy of +/-1% of reading +/-.2% at calibration point
– Reliable repeatable results
– Automatic temperature compensation
– Autoranging
– Accuracy of benchtop lab equipment in an affordable, portable compact pen
– Rugged, reliable, shock resistant fully encapsulated electronics, body constructed of aircraft aluminum
– Simple one-button function
– Specially designed with measurement ranges and solution modes to meet the water quality testing needs of many applications
– High-capacity N-type battery included
– Waterproof
Applications
– Agriculture
– Hydroponics
– Desalination
– Aquaculture
– Pharmaceutical
– Boilers and cooling towers
– Fountain solutions for printing
– Horticulture
– Wastewater
– Pool and Spa
– Food and beverage
– Irrigation
– Reverse Osmosis
Specifications
– Measurement Range: 1-9999 us or ppm (0.0010 – 9.999 ppt salinity)
– Accuracy: +/- 1% of reading
– Repeatability: 1000 uS or ppm +/- 0.3% of reading
– Resolution:
Electrical Conductivity (EC) and TDS:
– 0.1 for 1.0-99.9 uS or ppm
– 1 for 100-9999 uS or ppm
Salinity
– 0.0001 for 0.0010-0.0999 ppt
– 0.001 for 0.100 – 9.999 ppt
Temperature
– 0.1 °C or °F
– Time to Reading Stabilization: 10-20 seconds
– Active mode power consumption: 30-100 mA
– Sleep mode power consumption: 2 uA
– Temperature measurement range: 0-71°C or 32-160°F
– Temperature accuracy displayed: +/- 0.1 °C or +/- 0.2 F
– Temperature compensation method: Automatic 25 °C
– Physical Dimensions: 6.75″ L x 0.625″ D, 17.15 cm L x 1.59 cm D
– Weight: 55 g or 1.94 oz
– Case Material: Anodized aluminum with UV protective coating
– Battery type: N type, Alkaline
– Battery Voltage: 1.5 V
– Operating/Storage Temperature: 0-55 °C or 32-131°F
– Water Resistant: IP67 and NEMA 6
