Description
Motor: 1HP
Spindle Stroke: 130mm
Spindle Nose To Column Surface: 260mm
Cross Table: 585 x 190mm
Longitudinal Travel: 340mm
Cross Travel: 180mm
Column Diameter: 115mm
Number of Slots: 4
T-slots Size: 14 x 24mm
Dimensions (LXWXH): 839x737x1817mm
Weight (Net Gross): 280 310Kg
Cutting Capacity: Drilling 32mm (11 4 inch)
